JBL PA1502

JBL Apex PA1502

The Apex Series PA1502 powersports amplifiers deliver efficient Class D power, from an ultra-compact chassis, designed to fit into tight spaces and withstand outdoor environments without missing a beat.

Variations
$499.99499.99 each
Product Actions
Add to cart options

In stock. Estimated delivery time 2-4 business days



Features

Ultra-compact Aluminum Chassis

Ultra-compact Aluminum Chassis

JBL Apex powersports amplifiers feature an ultra-compact aluminum chassis and small footprint design to allow for installation almost anywhere.

Conformal-Coated PCB

Conformal-Coated PCB

JBL Apex powersports amplifiers are engineered to withstand harsh conditions, with fully “marinized” circuit boards to ensure flawless power delivery, year after year.

Big Dynamic Power

Big Dynamic Power

Dynamic Class D output power is perfectly matched to meet the needs for your JBL car, marine and powersports products.

Full-Range Outputs and Selectable Crossovers

Full-Range Outputs and Selectable Crossovers

The Apex PA1502 amplifier features selectable all-/hi-/lo-pass crossover filters, with selectable 12dB per octave electronic crossover slopes from 60-, 80-, 120Hz to allow for quick and easy installation.

High- and low-level inputs

High- and low-level inputs

Speaker-level and low-level inputs let JBL Apex amplifiers integrate with just about any audio input.

Harman Standard Reliability Testing

Harman Standard Reliability Testing

JBL Apex amplifiers have to go through environmental testing that would destroy other amplifiers. JBL freezes them, bakes them, shakes them, blasts them with ultraviolet light & salt spray and drives them at full power for days at a time.

JBL Industrial Design

JBL Industrial Design

JBL engineers every product with a high level of design. In applications where the Apex PA1502 will be visible, it will enhance the vehicles asthetic not take away from it.

Specs & Downloads

Item# PA1502

Product Description

JBL Pro Sound Designed to take a beating

The Apex Series PA1502 powersports amplifiers deliver efficient Class D power, from an ultra-compact chassis, designed to fit into tight spaces and withstand outdoor environments without missing a beat. Available with 2-channels of output power, the Apex Series PA1502 includes selectable electronic crossover frequency adjustment, with lo-pass capability & selectable bass boost, for quick and easy installation. Plus, it has been engineered for harsh conditions, with power and performance to meet the needs of most audio systems making it the perfect match for all of your JBL car, marine and powersports products.

General Specifications

Max Power 750W peak
RMS Power Output @ 2Ω (full-range) 150W x 2, <1% THD+N
RMS Power Output @ 4Ω (full-range) 100W x 2, <1% THD+N
RMS Power Output @ 4Ω Bridged (full-range) 300W x 1, <1% THD+N
Selectable all-/hi-/lo-pass filter 60-, 80-, 120Hz @ 12dB/octave
Selectable bass boost 0-, 6-, 12dB @45Hz
Frequency Response 20Hz – 20kHz
Signal-to-Noise Ratio (full-range) >75dB (ref 1W output @ 4Ω)
Fuse rating 25A

What's in the box?

  • 1 x Amplifier
  • 1 x Stainless steel mounting hardware
  • 2 x High-level input adapters
  • 4 x Zip ties
  • 1 x Spare fuse
  • 2 x JBL sticker
  • 1 x Quick start guide
